SCV-6023R

Discontinued

Copy a URL

Copy

1080p IR Vandal Camera

Key Features

• Full HD (1,920 x 1,080 30fps) resolution
• 0.25Lux@F2.1 (Color), 0Lux@F2.1 (B/W : IR LED on)
• Built-in 4mm fixed lens
• Day & Night (ICR), DWDR, SSNRIV, Motion detection
• IR viewable length 20m, IP66, IK10
• Transmission distance max. 500m
• Easy installation (Plug & play)

※ Product availability may vary by region.
Please contact your regional representative.

※ NDAA Compliant

Datasheet

Contact Sales

Mouse over image to zoom

Discontinued

URL 복사

복사

Image Download Total Image Download

SCV-6023R

1080p IR Vandal Camera

Key Features

※ Product availability may vary by region.
Please contact your regional representative.

SCV-6023R

Product Specification

Video
Lens
Pan / Tilt / Rotate
Operational
Environmental & Electrical
Mechanical

Video
Imaging Device		1/3" 2MP CMOS
Resolution		1920x1080
Max. Framerate		30fps
Min. Illumination		Color: 0.25Lux(F2.1) BW: 0.0Lux(IR LED on)
Video Out		BNC(AHD / CVBS selectable)
Video Transmission Distance		500m(75-5 coaxial cable)
Lens
Focal Length (Zoom Ratio)		4mm fixed focal
Max. Aperture Ratio		F2.1
Angular Field of View		H: 80.7° / V: 43.5° / D: 95.8°
Min. Object Distance		0.5m(1.64ft)
Focus Control		Manual
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range		0°~350° / 0°~67° / 0°~355°
Operational
Camera Title		Displayed up to 15 characters
Day & Night		Auto(ICR)
Backlight Compensation		UserBLC, HLC, DWDR
Digital Noise Reduction		SSNRⅣ
Defog		Support
Motion Detection		4ea
Privacy Masking		4ea, rectangular zones
Gain Control		Low / Midel / High
White Balance		ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed		1 ~ 1/12,000sec
Video Rotation		H-Rev / V-Rev
Analytics		Motion detection
IR Viewable Length		20m(65.62ft)
Coaxial Protocol		ACP(AHD Coax Protocol) CVBS: Pelco-C(Coaxitron)
Environmental & Electrical
Operating Temperature / Humidity		-30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH *Start up should be done at above -10°C (+14°F)
Certification		IP66, IK10, Safety(UL), EMC(FCC, CE)
Input Voltage		12VDC
Power Consumption		Max 4.2W
Mechanical
Color / Material		Ivory / Aluminum

• The latest product information / specification can be found at hanwha-security.com
• Design and specifications are subject to change without notice.
• Wisenet is the proprietary brand of Hanwha Techwin, formerly known as Samsung Techwin.
