SHB-4300HP
Fixed Camera Housing
Key Features
• For fixed camera application
• Aluminum diecasting construction
• Fully cable managed bracket
• De-mister heater, fan
• Support three cable glands, IP66
• 24V ACSHB-4300H1 : Extreme weather proof housing
• Aluminum diecasting construction
• Fully cable managed bracket
• De-mister heater, fan
• Support three cable glands, IP66
• 24V ACSHB-4300H1 : Extreme weather proof housing
※ Product availability may vary by region.
Please contact your regional representative.
※ NDAA Compliant
Mouse over image to zoom
SHB-4300HP
Fixed Camera Housing
Key Features
• For fixed camera application
• Aluminum diecasting construction
• Fully cable managed bracket
• De-mister heater, fan
• Support three cable glands, IP66
• 24V ACSHB-4300H1 : Extreme weather proof housing
• Aluminum diecasting construction
• Fully cable managed bracket
• De-mister heater, fan
• Support three cable glands, IP66
• 24V ACSHB-4300H1 : Extreme weather proof housing
※ Product availability may vary by region.
Please contact your regional representative.
SHB-4300HP
Product Specification
- Environmental
- Electrical
- Mechanical
-
-
Environmental Operating Temperature / Humidity -35°C ~ +50°C (-31°F ~ +122°F)
/ Less than 90% RHFan/Heater Support
(Heater : 5°C ± 5°C on / Blower : 35°C ± 5°C on)Certification IP66, CE (Class A) Electrical Input Voltage PoE+(IEEE802.3at, Class4), 12VDC Power Consumption 16W
FAN(2W) : 2W * 1EA
HEATER(9W) : 9W * 1EAMechanical Color Ivory Material Aluminum Product dimensions / weight Outside : 184(W)x127(H)x460(D)mm
Inside : 91(W)x78(H)x250(D)mmPan / Tilt / Rotate Range 0°~360° / 0°~90° Supported products Box cameras (Network)
※ For further compatible models, please visit our website or use Toolbox -
• The latest product information / specification can be found at hanwha-security.com
• Design and specifications are subject to change without notice.
